LulzBot TAZ 8: Built to Last, Built to Perform
Trusted by manufacturers, research labs, and production teams running multi-printer operations, the TAZ 8 thrives in environments where 24/7 printing and high part throughput are essential.
-
Engineered for Reliability: Optimized for continuous use, the TAZ 8 delivers consistent results across long jobs and large fleets. From the Mini 3 to the TAZ 8, every LulzBot machine speaks the same language—shared workflows, interchangeable parts, and familiar controls.
-
Low Cost of Ownership: With minimal maintenance and a long service life, the TAZ 8 offers excellent value. Modular, upgradable Tool Heads and quick-access components keep service simple and downtime low.
-
Made in the USA: Proudly designed, built, and supported in Fargo, North Dakota—ensuring fast, knowledgeable support and easy access to parts.
Empower Your Operations: Scalable, dependable, and easy to integrate, the TAZ 8 is print farm ready from day one!
Contact us for print farm discounts, leasing, and financing options.
Select the best Tool Head for your LulzBot TAZ 8 based on your specific printing needs.
Each option in the Galaxy Series is designed for different scenarios:
Meteor 175
- For 1.75mm Filament: Offers the widest range of color and material options.
- Best For: General printing across diverse materials.
Meteor 285
- Robust Filament Handling: Minimizes filament stretching, ideal for flexible materials.
- Best For: Printing with flexible materials like TPU.
Asteroid 285
- Large Layer Extrusion: Features a 100W heater and 1.2mm nozzle for larger prints.
- Best For: Faster printing of large items with thicker layers.
Twin Nebula 175
- Dual Extrusion for 1.75mm Filament: Allows for multi-material or multi-color printing.
- Best For: Projects requiring multiple materials or colors in one print.
Twin Nebula 285
- Dual Extrusion for 2.85mm Filament: Handles robust and flexible materials in dual-material prints.
- Best For: Dual-material prints involving flexible or thicker filaments.
Choose a Tool Head that aligns with your project requirements to enhance the performance and versatility of your LulzBot TAZ 8. Each Tool Head is engineered to maximize efficiency and quality, ensuring you get the most out of your 3D printing experience.
| TAZ 8 Specifications | |
| 3D Printing Technology | FFF (Fused Filament Fabrication) |
| Max Print Volume | 295 x 295 x 285 mm3 (11.5 x 11.5 x 11.2 in3) |
| Standard Tool Head Model | 🔗Any Galaxy Series Tool Head |
| Equipped Layer Height Range | 0.1mm (100 microns) to 0.4mm (400 microns) |
| Platform Layer Height Capabilities | 0.05mm (50 microns) to 1.8mm (1800 microns) |
| Nozzle Diameter & Material | 0.5mm Nickel Plated Brass |
| Maximum Hot End Temperature | 290°C (554°F) - Firmware Limited |
| XYZ Positional Resolution | X and Y axes - 0.01mm (10 microns), Z axis - 0.0019mm (1.9 microns) |
| Movement System | GT2 Belt Drive, Linear Rails X&Y, 12mm Igus SST Rods and Polymer Bushings Z |
| Maximum Travel Speed | 500 mm/s - Firmware Limited |
| Print Bed Heater | 360W 24V Silicon |
| Print Bed Material | 🔗Magnetic Flex Bed System |
| Maximum Print Bed Temperature | 110°C (230°F) |
| Filament Diameter Compatibility | 2.85mm or 1.75mm (Tool Head Dependent) |
| Filament Sensor | Runout and Stripping Detection |
| Mainboard | 32-bit Archim 2.2b with Trinamic TMC2130 drivers and Xpand board |
| Firmware | Marlin |
| Bed Leveling System | Automatic BLTouch 16-Point Mesh |
| Calibration | Automatic X-Axis True Tramming, Z-Offset, and Backlash Compensation |
| Power Supply | 500W 24V Mean Well, Auto-Switching |
| Power Input | 100VAC-240VAC |
| Slicer Software Recommendation | 🔗Cura LE (LulzBot Edition) |
| OS Compatibility | Windows, macOS, Linux |
| Supported File Formats | STL, OBJ, X3D, 3MF |
| Operating Temperature Range | 41°F to 113°F (5°C to 45°C) |
| Supported Print Materials | 🔗PLA, TPU, ABS, PETg, PVA, PVB, Nylon, PC, and others below 290°C |
| Enclosure | 🔗Optional Accessory Available |
| Connectivity Options | USB Serial, Includes 8GB SD Card for Standalone Printing |
| Certifications | - |
| Warranty | 🔗1-year standard with options for extended warranties |
| Country of Origin | USA |
Choose options
Machine Features
First-Ever Active Bed Cooling
Reduce cool-down times by over 50% with Active Bed Cooling, maintaining material integrity and speeding up production cycles.
Key Benefits:
- Reduces waiting times, enhancing efficiency.
- Prevents material deformation while speeding cooldown.
Precision Linear Rails in X & Y Axes
Consistent movement along the X and Y axes with Linear Rails, enabling faster print speeds and superior print quality.
Key Benefits:
- Allows for higher accelerations, reducing print times.
- Achieves precise positioning for impeccable print results.
Next-Generation User Interface
Navigate easily with a glove-friendly resistive touch screen and intuitive menus, enhancing control and efficiency.
Key Benefits:
- Operate the printer effortlessly, even with gloves on.
- Streamlined menus for quick, easy control of your 3D printing.
Advanced Filament Monitoring
Automatically detect filament issues like runout and jams to prevent print failures and minimize waste.
Key Benefits:
- Detects issues to stop problems before they affect the print.
- Ensures efficient use of filament, saving resources and time.
Tool-Free Tool Head Swapping
Quickly swap Tool Heads without tools using a magnetic cap and thumbscrews, reducing downtime and boosting flexibility.
Key Benefits:
- Swap Tool Heads quickly without the need for additional tools.
- Solid thumbscrews ensure each Tool Head is securely attached.
Advanced Bed Leveling
Achieve precise bed leveling with the BLTouch® probe, ensuring great first-layer adhesion and optimal print quality.
Key Benefits:
- Physical probing provides consistent leveling across the entire print bed.
- Achieves repeatable first-layers, crucial for final print quality.
Workspace Planning?
Get a life-sized TAZ 8 model to help plan your labs, shops, and workspaces.
Download Life-Sized TAZ 8 .STEPGet a desk-sized TAZ 8 model for space planning or for fun! Use 1.75mm filament for functional Z-axis movement!
Download 1:10 scale TAZ 8 .stl
TAZ 8 Print Farm in Action
Why Choose LulzBot?
Rugged Reliability
Built for industrial demands, delivering consistent results with minimal maintenance.
Made in the USA
Proudly manufactured in Fargo, ND, ensuring top-quality craftsmanship and reliable performance.
Committed Expertise
Expert support, available Monday–Friday, to keep your LulzBot 3D printer running without issue.
Versatile by Design
Adapt your LulzBot 3D printer for specialized performance and niche applications with ease.
